Shuttle XPC Slim XH810 Mini PC Barebones Sort
Varenr. · EAN
Pris ved login
priser efter jeres aftale
På lager
Levering 1–2 hverdage · bestil inden 15:00
Passer til jeres setup
Vi klargør maskinen med jeres Microsoft 365-profil, Intune-politikker og printere, før den sendes. I skal bare logge ind.
Skal udstyret sættes op på plads, tilføjer vi gerne en tekniker i kurven — sig til, så retter vi ordren inden den pakkes.
Beskrivelse
Shuttle XPC slim Barebone XH810 - S1851, Intel H810, 1xDP, 2xHDMI, 3x COM (RS232) , 2x Intel LAN,2x2.5", 8x USB, 3x M.2, 24/7 permanent operation, 3.5L sized PC, PC barebone, Intel H810, LGA 1851 (Socket V1), DDR5-SDRAM, 120 W
Specifikationer
| Processor manufacturer | Intel |
| Built-in processor | No |
| Internal memory installed | No |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 96 GB |
| Supported memory clock speeds | 5600 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory voltage | 1.1 V |
| ECC | No |
| Non-ECC | Yes |
| Storage drives installed | No |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| On-board graphics card | Yes |
| Graphics card family | Intel |
| Motherboard form factor | mini ITX |
| Motherboard chipset | Intel H810 |
| Processor socket | LGA 1851 (Socket V1) |
| Number of processors supported | 1 |
| Compatible processor series | Intel Core Ultra (Series 2) |
| BIOS type | AMI EEPROM |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | ALC 888S |
| Built-in speaker(s) | No |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| LAN controller | Intel I226-LM, Intel® I219-LM |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0/2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4a |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Serial ports quantity | 3 |
| DC-in jack | Yes |
| Chassis type | 3.5L sized PC |
| Product colour | Black |
| Cooling type | Active |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Product type | PC barebone |
| Compliance certificates | Federal Communications Commission (FCC), CE, UKCA, BSMI, RCM, VCCI, RoHS |
| Harmonized System (HS) code | 84733080 |
| Sustainability certificates | ENERGY STAR, ErP |
| Power supply type | External AC adapter |
| Power supply | 120 W |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
