Barebone Server Gigabyte Barebone R263-ZG0-AAL2 (Rev. 3.x) Rack Server 2U Single Sockel SP5 6NR263ZG0DR000ACL2
Art.-Nr. · EAN
Preis nach Anmeldung
Preise gemäß Ihrer Vereinbarung
Auf Lager
Lieferung 1–2 Werktage · Bestellung bis 15:00
Beschreibung
GIGABYTE R263-ZG0-AAL2, LGA 6096, AMD EPYC 9005, AMD EPYC 9004, GDDR5, Dodeca-channel, 2.5,3.5,M.2, 0, 1, 5, 10
Spezifikationen
| Built-in processor | No |
| Processor socket | LGA 6096 |
| Number of processors supported | 1 |
| Compatible processor series | AMD EPYC 9005, AMD EPYC 9004 |
| Number of DIMM slots | 24 |
| Supported memory types | GDDR5 |
| Memory channels | Dodeca-channel |
| Number of storage drives supported | 14 |
| Hot-swap HDD bays | Yes |
| Number of 2.5" bays | 12 |
| Number of 3.5" bays | 12 |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| RAID levels | 0, 1, 5, 10 |
| On-board graphics card model | Aspeed AST2600 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Number of M.2 (M) slots | 2 |
| Trusted Platform Module (TPM) | Yes |
| Backplanes support | Yes |
| Chassis type | Rack (2U) |
| Product colour | Black, Steel |
| LED indicators | HDD, LAN, Power, System |
| On/off switch | Yes |
| Reset button | Yes |
| Cooling type | Active |
| Number of fans | 4 fan(s) |
| Fan diameter | 8 cm |
| Power supply | 2700 W |
| Number of main power supplies | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 12 - 16 A |
| 80 PLUS certification | 80 PLUS Titanium |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Width | 438 mm |
| Depth | 815 mm |
| Height | 87.5 mm |
| Weight | 29.4 kg |
| Packaging content | 1 x R263-ZG0-AAL2 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 1 x GPU power cable (16-pin, 250mm) 2 x GPU power cables (16-pin, 450mm) 1 x GPU power cable (16-pin, 550mm) 1 x 2-Section Rail kit |
| Package width | 1082 mm |
| Package depth | 685 mm |
| Package height | 314 mm |
| Package weight | 31.4 kg |
